Lenovo ThinkStation P340 Tower i7-10700/ 1TB
Front View
| 1. | Optical drive eject button | 2. | Optical drive activity indicator |
| 3. | Flex bay | 4. | Internal speaker |
| 5. | ThinkStation® LED | 6. | Power button |
| 7. | Storage drive activity indicator | 8. | SD-card slot |
| 9. | Microphone connector | 10. | Headset connector |
| 11. | USB-C™ (3.2 Gen 1) connector | 12. | USB 3.2 connectors Gen 1 |
| 13. | USB 3.2 connectors Gen 2 |
Rear View
| 1. | Audio line-out connector | 2. | DisplayPort® out connectors |
| 3. | Optional connector | 4. | USB 2.0 connectors |
| 5. | USB 3.2 connector Gen 1 (supports smart power on) | 6. | USB 3.2 connector Gen 1 |
| 7. | PCI-Express card area | 8. | Serial connector |
| 9. | Padlock loop | 10. | PS/2 keyboard and mouse connectors |
| 11. | Ethernet connector | 12. | E-lock slots |
| 13. | Serial connector | 14. | Smart cable clip slots |
| 15. | Security-lock slot | 16. | Power cord connector |
| Lenovo ThinkStation P340 Tower (30DHS05Q00) | |||||||||
| 30DHS05Q00 | Intel Core i7-10700(8 cores / 16 Threads) | 8 GB UDIMM DDR4-2933 non-ECC | 1x 1 TB HDD 7200rpm | Integrated Intel UHD Graphics 630 | Windows 10 Pro 64 | 3 Year On-Site | |||
| General Specification | |
|---|---|
| Type: | Workstation |
| Operating system: | • Windows 10 Pro for Workstations • Windows 10 Pro • Ubuntu® Linux® • Redhat® Linux® (certified) |
| Processor / Chipset | |
| Processor: | • Up to Intel® Xeon® W-1290P with vPro™ (3.70GHz, up to 5.30GHz with Turbo Boost, 10 cores, 20MB Cache) • Up to 10th Generation Intel® Core™ i9-10900K Processor with vPro™ (3.70GHz, up to 5.30GHz with Turbo Boost, 10 cores, 20MB Cache) |
| Chipset: | Intel W480 |
| Memory | |
| Memory: | • 8 GB DDR4 2667MHz • Up to 128GB DDR4 2933MHz • UP to 128GB DDR4 2933MHz ECC |
| Type: | DDR4 |
| Memory DIMM Capacity: | • 4GB / 8GB / 16GB / 32GB ECC • 8GB / 16GB / 32GB non-ECC |
| Dimensions And Weight | |
| Width: | 170 mm (6.7 in.) |
| Depth: | 315.35 mm (12.4 in.) |
| Height: | 376 mm (14.8 in.) |
| Weight: | 9.4 kg (20.7 lb) |
| Ports/Slots | |
| Front Ports: | • 2 x USB 3.2 Gen 2 Type-A • 2 x USB 3.2 Gen 1 Type-A • USB 3.2 Gen 1 Type-C • Audio jack • Mic jack |
| Rear ports: | • 2 x USB 2.0 Type-A • 2 x USB 3.2 Gen 1 Type-A • Audio (line out) • 2 x Display Port (3rd DP optional) • RJ45 (1GB Ethernet) • Serial port (2nd serial optional) • Thunderbolt (optional) |
| Expansion Slots: | • (1) PCIe 3.0 x16 • (1) PCIe 3.0 x1 • (1) PCIe 3.0 x4 |
| Security | |
| Security: | • Trusted Platform Module (TPM 2.0) • Self-healing BIOS • Supervisor, SMP and power-on passwords • Electronic lock support • Chassis intrusion detection • UEFI secure boot support • HDD password protection for HDD Data • Windows UEFI firmware update support • Device Guard Support • Optional: Access panel lock, Kensington lock slot, pad lock slot, BIOS guard, boot guard |
| Graphics | |
| Graphics: | • Integrated Intel® UHD Graphics 630 • NVIDIA® Quadro P400 2GB • NVIDIA® Quadro P620 2GB • NVIDIA® Quadro P1000 4GB • NVIDIA® Quadro P2200 5GB • NVIDIA® Quadro RTX4000 8GB • NVIDIA® Quadro RTX5000 16GB |
| Storage | |
| Storage: | • Up to 6 total drives • Max M.2 = 4 (8TB) • Max 3.5″ = 2 TWR (12TB); 1 SFF (6TB) • Max 2.5″ = 2 TWR (2TB); 1 SFF (1TB) |
| Raid: | • M.2 = 0/1 (TWR/SFF) • SATA = 0/1/5/10 (TWR); 0/1 (SFF) |
| Storage Type Capacity: | • M.2 PCIe NVMe SSD up to 2TB • 3.5″ SATA 7200rpm up to 6TB • 2.5″ SATA SSD up to 1TB |
| Removable Storage: | • (1) 3-in-1 Media Card Reader • (1) Slim ODD • (1) Front Accessible Drive Tray |
| Certifications | |
| ISV Certifications | • Altair® HyperWorks • ANSYS® ANSYS • Autodesk® Alias/VRED, AutoCAD, Inventor, Revit • Avid® Media Composer • Bentley® MicroStation • Dassault® 3DEXPERIENCE, SOLIDWORKS • Nemetschek® Vectorworks • PTC Creo® • Siemens® NX, Solid Edge, Teamcenter, Tecnomatix • Barco Medical Displays • McKesson Medical Imaging |
| Green Certifications: | • ENERGY STAR® 8.0 • EPEAT™ • GREENGUARD • RoHS Compliant • 80 PLUS Platinum (500W) • 80 PLUS Gold (300W) |
| Power Supply | |
| Power Supply: | • 300W (90% efficient) • 500W (92% efficient) |
| Connectivity | |
| Connectivity: | • Intel® WiFi 6™ AX201 802.11AX (2 x 2) & Bluetooth® 5.0 (Optional) • Intel® WiFi 6™ AX201 802.11AX (2 x 2) & Bluetooth® 5.0 with vPro™ (Optional) |
