Lenovo ThinkStation P340 Tiny
| 1. | System status indicator | 2. | Power button |
| 3. | Storage drive activity indicator | 4. | USB-C™ (3.2 Gen 1) connector |
| 5. | Always On USB 3.2 connector Gen 2 | 6. | Headset connector |
| 7. | Security-lock slot | 8. | Optional connectors |
| 9. | Wi-Fi antenna slot | 10. | Ethernet connector |
| 11. | USB 3.2 connectors Gen 2 | 12. | USB 3.2 connector Gen 1 (with smart power-on) |
| 13. | HDMI™ 1.4 out connector | 14. | USB 3.2 connector Gen 1 |
| 15. | DisplayPort 1.4 out connector | 16. | Power cord connector |
General Specification
| Type: | Workstation |
| Operating system: | • Windows 10 Pro – Lenovo recommends Windows 10 Pro for business • Windows 10 Home • Ubuntu® Linux® • Red Hat® Linux® (supported) |
| Processor / Chipset | |
|---|---|
| Processor: | Up to 10th Generation Intel® Core™ i9-10900 with vPro™ (2.8GHz, up to 5.1GHz with Turbo Boost, 10 Cores, 20MB Cache) |
| Chipset: | Intel Q470 |
| Memory | |
| Memory: | Up to 64GB |
| Type: | DDR4 |
| Memory DIMM Capacity: | • 4GB / 8GB / 16GB / 32GB • 2 SoDIMM Slots |
| Dimensions And Weight | |
| Width: | 36.5 mm (1.4 in.) |
| Depth: | 182.9 mm (7.2 in.) |
| Height: | 179 mm (7.0 in.) |
| Weight: | 1.32 kg (2.91 lb) |
| Ports/Slots | |
| Front Ports: | • USB 3.2 Gen 2 Type-A • USB 3.2 Gen 1 Type-C • Headphone / mic jack |
| Rear ports: | • 2 x USB 3.2 Gen 2 Type-A • 2 x USB 3.2 Gen 1 Type-A • DisplayPort™ • HDMI • RJ45 (1 Gb Ethernet) • WiFi Dipole Antenna (standard with WiFi card) • 4 x Mini-DisplayPort (standard with discrete graphics) |
| Expansion Slots: | • Serial/DP/HDMI/TypeC-DP/VGA • Thunderbolt™ 3 |
| Security | |
| Security: | • Trusted Platform Module (TPM 2.0) • Kensington® lock slot to secure bottom door |
| Graphics | |
| Graphics: | Up to NVIDIA® Quadro® P1000 4GB |
| Connectivity: | • Optional: Intel® 9560 802.11 AC vPro™ (2 x 2) + Bluetooth® 5.0 • Optional: Intel Wi-Fi 6 AX 201 2*2AX + Bluetooth 5.0 |
| Storage | |
| Storage: | • Up to 2 total drives • Max M.2 = 2 (4TB) |
| Storage Type Capacity: | M.2 PCIe NVMe SSD up to 2TB |
| Raid: | 0/1 |
| Certifications | |
| ISV Certifications | • Autodesk® AutoCAD, Inventor, Revit • AVEVA® PDMS • Avid® Media Composer • Bentley® MicroStation • Dassault® 3DEXPERIENCE, SOLIDWORKS • Nemetschek® Vectorworks • PTC Creo® • Siemens® NX, Solid Edge, Teamcenter, Tecnomatix • McKesson Medical Imaging |
| Green Certifications: | • EPEAT® Silver • Energy Star 8.0 • GREENGUARD® • RoHS Compliant |
| Power Supply | |
| Power Supply: | • 170W (89% efficient) • 230W (89% efficient) |
| Connectivity | |
| Connectivity: | • Optional: Intel® 9560 802.11 AC vPro™ (2 x 2) + Bluetooth® 5.0 • Optional: Intel Wi-Fi 6 AX 201 2*2AX + Bluetooth 5.0 |
